Lode Rehab Manager

Lode Rehab Manager

Lode Rehab Manager

Simultaneous testing
The Lode Rehab Manager software is developed to connect multiple Lode ergometers and / or treadmills to one PC. Patients, devices and protocols can be managed simultaneously. The software can control 2 up till 16 ergometers.Various ergometry parameters can be controlled:

Workload
BPM
SpO2
Heartrate
RPM
BORG Scale
Heartrate controlled ergometry

The standard software package provides a license for two ergometers, a network module connection cable (#930930) and a 5m cat cable. When using more than two ergometers, an additional license (#950906) can be ordered separately for each ergometer.
Interconnectivity between Lode products

SKU: 17-Rehab Category:

Overview

Highlights

High standards

Lode is a socially and environmentally responsible company. All Lode products are RoHS/WEE compliant and Lode is ISO 9001:2015, ISO and 13485:2016 certified. All medical products comply to MDD 93/42/EEC, incl. IEC 60601-1.

Everything in control

Easy set up of Subject data
Create protocols quickly and efficiently
Overview of progress during test

Multifunctional software for all Lode ergometers

The software can be used for all Lode ergometers and treadmills, including their options like bloodpressure, heart rate, SpO2 etc.
Load as well as bloodpressure triggers can be set remotely.

Easy to install

– Simple step by step installer
– Easy setup of ergometers
– Easy setup of subjects

Complete Ergometry setting

The modular structure of the software combined with the accurate and reliable Lode ergometers offers a complete and modern ergometry setting.

Features

Rehabilitation

Patient Database

An extensive patient database is available, which can work as a stand alone database or linked to a SQL server. HL7 connection to the Hospital Information System (HIS) is possible.

Data dashboard available

Various ergometry data is made visible, enabling the operator to simultaneously visualize ergometric parameters during the test and to control or quickly intervene when necessary.

Monitor

Monitor during the test

RehabilitationThe visualisations on the monitor can be selected by the operator to define a clear and usefull visual overview during the exercise test. The lay-outs for different purposes can be saved by the operator

Add remarks

Remarks can be added and modified before, after and
during the test

Clear results

Multiple analysis modes

Easy access to Analysis menu. Creating individual comparisons with an overview of the performed tests.

Borg RPE scale integrated

Ratings of Perceived Exertion: an aid to help estimate the amount of exertion, the load and fatigue on a scale of 6 to 20.

Easy guided protocol creation

Protocol Wizard for creating standard protocols for the bicycle ergometer or treadmill. An efficient manner to define the amount, duration and type of stages, in interval- step- or bodyweight controlled- protocols.

Sophisticated analysis menu

Possibility to zoom into the results and synchronize with other graphs. To have a better look with the use of the x/y coordinate functionality. Compare several test results from a Test subject in a clear overview, or compare different test subject performing the same exercise test. Define your own print report.

HL7 compatible

Specific data and reports can be exchanged with hospital information systems according to the HL7 standard

Protocol editor

Exercise Protocols with target energy and target distance stages are created with the protocol editor. Special ramping stages or Heart rate controlled protocols are easily programmed. With the edit functionality the exercise protocols are adjusted in a second. Default protocols are available.

Specifications

Comfort
Alarm Heart Rate
Alarm Heart Rate
Alarm Blood Pressure
Alarm Blood Pressure
Audio Alarm
Audio Alarm
Versatile database connection
Versatile database connection
User Interface
Customized Screenviews
Customized Screenviews
Customized Reports
Customized Reports
Personalized Color Settings
Personalized Color Settings
Software available in English
Software available in English
Software available in German
Software available in German
Software available in Dutch
Software available in Dutch
Software available in French
Software available in French
Software available in Russian
Software available in Russian
Software available in Polish
Software available in Polish
Software available in Japanese
Software available in Japanese
Connectivity
RS232 connection to Lode ergometers
RS232 connection to Lode ergometers
USB connection to Lode treadmills
USB connection to Lode treadmills
Bluetooth available
connectivity through Bluetooth available
Max. wireless slots per monitor 8 the maximum number of test subject that can be connected
Minimum System Requirements
Intel Core based processor 2.4 GHz processor family
Monitor 1920 x 1080 pixels Resolution
Internal RAM 4000 MB minimum PC internal memory
Minimum Free Hard Disk space 20 GB software and storage size requirement
CD Rom drive required
installation medium input
Number of free USB ports 1 for connection purposes
Mouse
for input
Keyboard
for input
Compatibility
HL7 compatible
HL7 compatible
Compatible with MS SQL Server
Can be connected with MS SQL Server
Database SQL Compact Database used
Database limit 4 GB Database limit when used as local database
Microsoft Windows 10
compatible with Microsoft Windows 10
Microsoft Windows 8
compatible with Microsoft Windows 8
Microsoft Windows 7
compatible with Microsoft Windows 7
Included parts

PC software included

*Specifications are subject to change without notice.

Related Products

Accessories

[wcsp_cross_sell orderby=”rand” order=”ASC” product_num=”5″ display_columns=”3″ title=”” product_id=”5368″]

Support

Q - Is it possible to control the Lode ergometers and treadmills with external equipment

Yes, you can find interface sheets for most common devices on the website at the "service" tab of this website. If your device is not present you can ask us to support you. In most cases we can quickly provide you with a solution.

Q - Can the Valiant be controlled by LCRM?

Yes the Valiant Treadmill can be controlled by LCRM. The treadmill is supplied with a RS232 port and can be controlled by a seperate com port.

Q - Is the SpO2 option compatible with LCRM?

Yes the SpO2 results are visible during the rehab session.

Q - How do I switch off the ECG module.

For turning off the legacy ECG module (950910/950913) - Hold the power button for a few seconds until the LED turns an amber color. Continue holding the button until the LED blinks and goes amber again. On the second amber flash, release the power button. This will power down the device.

Q - Can I loop Lode rehab products easily?

Yes! It is very easy to create a comfortable rehab setting with Lode rehab products by looping the ergometers:

Service

Part number
950905
